Exploring the impact of constraints on a solar farm in the National Electricity Market

by Jack Simpson
written by Jack Simpson

Earlier this week I came across an article about how New England Solar was planning to sell off its solar farms in Australia due to the impact of network congestion:

New Energy Solar’s CEO Liam Thomas said a flood of new projects had resulted in curtailment challenges spreading to other parts of the grid and cut the output of the Manildra solar farm by 40 per cent just as the company was looking for a buyer.

I thought that it would be interesting to dig into some of AEMO’s constraints data in order to investigate exactly how Manildra Solar Farm has been impacted by network congestion in FY-21.

Interestingly, it appears that the vast majority of the time a constraint impacted this solar farm, it could be attributed to a single factor: the 132 KV Molong to Orange North transmission line which you can see in the map below. This transmission line has a thermal limit that determines how much power can flow through it from generators in the area.

Continue Reading
0 comments
0 FacebookTwitterPinterestEmail
ContentEnergyFeaturedVisualisations

Big Battery Bidding and Rebidding!

by Jack Simpson
written by Jack Simpson

In the National Electricity Market (NEM), power stations can bid in their availability in 10 different pricing tranches. They’re able to rebid this availability right up until dispatch is run.

Recently, I was exploring this bidding data and thought I’d take a peak at what the bidding behaviour of the Hornsdale (Tesla) battery looked like in the energy market.

I’d known for a while that the big batteries did a lot of rebidding, but I was blown away by just how frequent it was! In a single day (2019-01-01) the battery made almost 13,500 rebids! In fact, for the first interval of the day, the battery made almost 300 rebids in the week leading up to dispatch.

I do find it interesting how they appeared to be doing so many identical rebids – I suspect there must be some automated process going on that will rebid in all markets regardless of whether the rebid in a particular market is any different to the bid that it replaced.

0 comments
0 FacebookTwitterPinterestEmail
ContentEnergyFeaturedVisualisations

How does a gigawatt of renewables disappear?

by Jack Simpson
written by Jack Simpson

One of the fun things about playing with hundreds of millions of rows of energy market data is that you can just go hunting through it for interesting anomalies. I recently found a fascinating anomaly exploring variable renewable energy (VRE – wind/solar farms) generation in Victoria on the 16th of November 2020

The figure below shows the combined output of every wind and solar farm in the state on a five minute basis between 11:30am and 3:30pm.

Continue Reading
0 comments
0 FacebookTwitterPinterestEmail
BloggingContentEnergyLinks

Virtual power plants, Texas ‘big freeze’ event, and grid visualisation tips video

by Jack Simpson
written by Jack Simpson

Here’s a few interesting pieces of energy-related content I’ve come across this week.

1. SolarQuotes have put up a video about their experience participating in a virtual power plant. In the video they cover:

  • How AGL was using their battery during the trial
  • Being aware of changes to feed in tariffs
  • The impact that electric vehicles can have on your consumption
Continue Reading
0 comments
0 FacebookTwitterPinterestEmail
ContentEnergyExplanationsFeaturedTips & Tutorials

Summary of reliability forecasting in the NEM

by Jack Simpson
written by Jack Simpson

I’ve written this article as a guide to the different reliability forecasts that AEMO undertakes in the National Electricity Market (NEM). These forecasts help AEMO identify supply shortfalls, and plan for the future. For example, AEMO’s annual Summer Readiness Plan draws on the outputs of most of the models described here.

This article is under active revision. My plan is to continue to tweak and expand on this content as I continue to learn more about these models. At the moment, this article covers the following topics:

  • LT PASA
  • MT PASA
  • ST PASA
  • EAAP

Long Term Projected Assessment of System Adequacy (LT PASA)

Purpose
  • Published annually looking out 10 years as part of the Electricity Statement of Opportunities (ESOO)
  • The forecast is used to identify reliability gaps in the first five years (which helps inform the RRO)
  • The final five years indicates whether there will be any future gaps in reliability
  • Informs the market on the need for new investment
  • Helps AEMO determine whether it needs to procure additional reserves
Inputs
  • Demand traces
    • Two scenarios: Probability of Exceedance (PoE) 10 and 50 (expect to exceed every 10 or 2 years)
  • Weather traces – 8 historic weather patterns:Wind/solar generation traces
    • Rooftop solar generation traces
    • Generator ratings and forced outages
  • Demand-side participation (DSP)
  • Transmission constraint equations (e.g. transmission line thermal ratings)
Outputs
  • ESOO report flagging breaches to the reliability standard
  • The ESOO Plexos model and input traces is available for download from AEMO’s site
Continue Reading
1 comment
0 FacebookTwitterPinterestEmail
ContentEnergyExplanations

What is the Reliability Standard and Settings?

by Jack Simpson
written by Jack Simpson

The reliability standard is the threshold used to determine whether there will be enough future capacity in the National Electricity Market (NEM) to meet demand. A breach of the standard (based on the LT and MT PASA forecasts that AEMO conducts) signals to investors that there will be a supply/demand imbalance.

Every four years the Reliability Panel will review the reliability standard and settings in the NEM.

Reliability Standard

The reliability standard is used to determine whether there is sufficient capacity within the NEM to meet demand.

It is defined as the proportion of expected unserved energy (USE – measured in GWh) relative to the total demand in a region over a financial year. The standard is currently set at 0.002% – this means that 99.998% of forecast annual customer demand is to be met.

It is worth noting that:

  • The standard only considers the impact of credible contingencies (e.g. generators, interconnectors, transmission)
  • Distribution reliability isn’t counted
  • It’s possible that a combination of weather events in a particular year could lead to a higher than expected level of load shedding as the standard is defined in terms of the maximum expected unserved energy
Continue Reading
1 comment
0 FacebookTwitterPinterestEmail
Hornsdale Power Reserve
ContentEnergyFeaturedVisualisations

Visualising the Tesla big battery at Hornsdale

by Jack Simpson
written by Jack Simpson

Lately I’ve been working with AEMO’s 4-second interval data from the National Electricity Market (NEM). Visualising the grid at this resolution is so fascinating, and I wanted to share a couple of figures I’d generated looking at the Hornsdale Power Reserve (the big Tesla battery). The figures have also raised a couple of questions for me which I’ve recorded below.

In all the figures, the battery has no dispatch target – rather it is responding to the automatic generation control (AGC) regulation instructions. In the figures:

  • Left y axis:
    • MW is what the battery was doing
      • Positive values mean the battery is discharging
      • Negative values mean the battery is recharging
    • Target Ramp is the dispatch target of the generator
    • Target Ramp + Reg adds in the regulation component to the target
  • Right y axis:
    • Hz is the mainland system frequency
2020-08-08 09:00-09:30
2020-08-08 23:00-23:30
Continue Reading
0 comments
0 FacebookTwitterPinterestEmail
ContentEnergyExplanations

What is the Retailer Reliability Obligation (RRO)?

by Jack Simpson
written by Jack Simpson

Commencing in 2019, the Retailer Reliability Obligation (RRO) requires energy retailers (plus some large energy users) to support reliability in the National Electricity Market (NEM) by holding contracts or investing directly in generation/demand response.

The RRO is exercised through two instruments:

RRO T-3 Instrument

  • Triggered 3 years and 3 months before an identified gap to the reliability standard
  • AEMO forecasts breaches to the the reliability standard as part of their Long Term Projected Assessment of System Adequacy (LT PASA) modelling which they publish in their annual Electricity Statement of Opportunities (ESOO) report
  • If a breach is forecast, retailers need to increase their contracting with existing generators and/or unlock new investment

RRO T-1 Instrument

  • Triggered 1 year and 3 months before an identified gap
  • AEMO forecasts breaches to the reliability standard as part of their Medium Term Projected Assessment of System Adequacy (MT PASA) modelling
  • If a breach of the standard is forecast, liable entities must report their net contract position to the Australian Energy Regulator (AER) for assessment

Sources

1 comment
0 FacebookTwitterPinterestEmail
